The GENESIS Multi-Plane Chest embodies the best in cable-based functional training. It can accommodate movement progressions from seated to standing and from one arm to two, with full range of motion. This versatility gives trainers (and users) the ability to program just about any sport- or life-specific exercise through all planes of movement. Add a bit more challenge by exercising standing behind the machine, adding rotation or including accessories like stability balls to test balance.
Freedom to Move
The swivel pulley design combined with the extensive cable travel allows users a wide, fluid range of motion.
Movement Variety
Handles move independently for single and alternating arm exercises.
Walk Up and Work Out
With no required adjustments, users can simply walk up, grab the handles and start moving.
Wheelchair Accessible
The open design makes it wheelchair accessible, welcoming to users of all abilities.
Walk Up and Work Out
With no required adjustments, users can simply walk up, grab the handles and start moving.
Unlimited Workout Options
Progress movements from seated to standing and add rotation to keep workouts evolving as fitness improves.
Details & Specs
Features
Extensive Cable Travel
Cable length allows for full flexion and extension. Single arm: 76 in / 193 cm, two arms: 38 in / 96.5 cm.
Padded, Contoured Seat
For beginning users or those looking to isolate the lower body, the seat features contoured padding for a comfortable fit.
Enclosed Weight Stack
The weight stack is enclosed to limit access to moving parts for safety.
Built to Last
Constructed with 11- and 7-gauge steel and electrostatically powder-coated, this machine is built to stand up to the rigors of the weight room.
Kick Plates
Large, 16-gauge, stainless steel kick plates protect the machine from wear and tear.
Specifications
Product Features
Instructional PlacardsYes
AdjustmentsN/A
Resistance1 arm: 100 lb / 45.3 kg 2 arms: 200 lb / 90.7 kg
SeatVinyl, 4.5 in / 11.4 cm thick foam
PulleysSwivel pulleys
Cable Travel38 in / 96.5 cm
Rubber FeetMolded floor protectors
Maximum User Weight350 lb / 159 kg
Americans with Disabilities Act (ADA)Wheelchair Accessible
Product Specifications
Weight Stack200 lb / 90 kg
Drop Down WeightN/A
Weight Stack Configuration5-50 x 5 lb / 2.2-22.6 x 2.2 kg 60-200 x 10 lb / 27.2-90.7 x 4.5 kg
Standard Frame ColorBlack River, Flat Black, Platinum Sparkle, White River
Optional Frame ColorCustom colors available upon request
Plastic ColorEbony
Standard Upholstery ColorBlack, Graphite, Blue Ridge, Burgundy, American Beauty Red
Optional Upholstery ColorCustom colors available upon request
Product Dimensions & Weight
Dimensions L x W x H69 x 53 x 73 in / 175.2 x 134.6 x 185.4 cm
Footprint69 x 53 in / 175.2 x 134.6 cm
Weight487 lb / 220 kg
Shipping Dimensions71 x 53 x 78 in / 80.3 x 134.6 x 198 cm
